جهاز اختبار الشد الإلكتروني العالمي أحادي العمود GBL-H2
نبذة عن المنتج
The GBL-H2 Universal Single-column Electronic Tensile Testing Machine is a mechanical property testing instrument independently developed and manufactured by Guangzhou GBPI R&D team, in compliance with the requirements of standards such as GB and ASTM as well as market demands.
Equipped with high-precision sensors, the instrument features high force measurement accuracy, stable loading, and long service life. The LCD screen, integrated with professional software, displays test curve data in real time and supports test report query, ensuring convenient and efficient testing. With fully automatic operation and control of the measurement unit, it is furnished with comprehensive safety protection functions including limit protection, overload protection, and emergency stop.
Suitable for mechanical property tests such as tension, peeling, heat sealing, tearing, and puncturing of various metal and non-metal materials, the instrument meets the test technology requirements of national technical supervision departments. It is widely applied in quality control of plastic film, food, and pharmaceutical manufacturers, as well as scientific research and teaching experiments in testing institutions and schools.
Test Principle
Fix the treated sample between the two chucks of the fixture, and start the instrument to make the two chucks move relatively. The force sensor installed on the movable chuck collects the force changes during the test, while the built-in displacement sensor of the machine captures the displacement changes, so as to calculate the performance indicators of the sample such as tension, peeling, heat sealing, and tearing.
Tensile test principle diagram
Standard
GB 8808
、
GB 13022
、
GB/T 1040
、
GB 4850
、
GB/T 7753
、
GB/T 7754
、
GB/T 453
、
GB/T 17200
、
GB/T 16578.1
、
QB/T 1130
、
GB/T 2791
、
GB/T 2790
、
GB/T 2792
、
GB/T 7122
、
GB/T 10004
、
GB/T 17590
、
JJG 139
、
GB/T 6344
、
GB 10808
、
YBB 00112003
、
YBB 00102003
、
YBB 00132002
、
YBB 00202004
、
ASTM D828
、
ASTM E4
、
ASTM D882
、
ASTM D1938
、
ASTM D3330
、
ASTM F904
、
JIS P8113
、
QB/T 2358
Specifications
Item
Technical Parameters
Force Measurement Range
0~300 N (0~500 N optional)
Force Measurement Accuracy
Within ±0.5 %FS of indicated value (Class 0.5)
Test Speed
0~500 mm/min (stepless speed regulation)
Displacement Precision
Within ±0.5% of indicated value
Effective Test Width
30 mm (50 mm, 60 mm customizable)
Effective Test Stroke
750 mm (1000 mm, 1200 mm customizable)
Dimension (L×W×H)
600 mm×500 mm×1300 mm
Weight
65 kg
Power Supply
AC 220 V, 50 Hz
Application
Plastic film
It is suitable for tensile, peeling, heat sealing, tearing, puncturing, compression, bending and other performance tests of plastic films, composite materials, flexible packaging materials, tapes and other products.
Composite film bag
It is suitable for tensile, peeling, heat sealing, tearing, puncture, compression, bending and other performance tests of composite films, co-extruded films, composite bags, retort bags, aluminum-plastic composite bags and other products.
Paper
It is suitable for tensile strength, peeling, deformation, tearing, heat sealing, bonding and other performance tests of paper, kraft paper, facial tissue, toilet paper and other products.
Medical Patches
It is suitable for tensile strength, peeling, deformation, tearing, heat sealing, bonding and other performance tests of medical cold compress, plaster and other products.
Pressure Sensitive Tapes
It is suitable for tensile strength, peeling, deformation, tearing, heat sealing, bonding and other performance tests of cellophane tape, electrical insulating tape, medical zinc oxide adhesive tape and other products.
Product Features
Elegant, Compact and User-friendly Machine Design
Desktop column structure with an elegant and compact appearance, enabling seated operation for maximum comfort.
Flexible, Versatile and Efficient Testing Methods
Capable of conducting tests including tension, peeling, heat sealing, tearing, and puncturing; supports multi-parameter setting such as width, speed, thickness, and chuck spacing.
High sampling rate (100 times/second) ensures accurate and reliable test data.
Safe and High-end Mechanical Structure
Three-level safety protection; equipped with an emergency stop switch for guaranteed safety; adopts imported core components for high precision and long service life; LCD screen displays test data and working status in real time.
Intelligent Operating System
Supports user management, permission management and audit trail, complying with the requirements of Annex to GMP <Computerized Systems>.
Flexible setting of test process parameters meets the requirements of non-standard tests and scientific research tests.
Allows standalone testing without a computer with automatic data processing; built-in micro-printer enables real-time data printing. The instrument is also equipped with a computer interface for online testing via PC connection.
Laboratory Intelligent IoT Platform (Optional)
Supports access to the laboratory intelligent IoT platform, realizing functions such as test data management and remote fault diagnosis and troubleshooting.
